DETECTION OF INCIDENTS IN TUNNELS

Automated detection and alert

Automated incident detection in transport tunnels is a vitally important safety initiative. Without automated incident detection, monitoring officers may be alerted to an incident only by use of an emergency telephone or a heat detector, minutes after the incident occurred. Fast incident detection and verification is crucial in preventing major tragedies in tunnels.

The Tunnel Incident Detection System

Specific features

• Continuous analysis of images from in-tunnel surveillance cameras
• Automated incident detection within seconds e.g. stationary vehicle, smoke, dropped object, slow traffic...
• Automated incident alert to tunnel control operators, providing immediate response to emergencies
• Visual verification of incidents
• Optional SCADA interface

Common Features

• Detection Camera

  • - Installed on an extension arm above traffic signals or on any suitable structure giving a clear view of the areas to be monitored.
• Outputs
  • - 4 opto-isolated solid state relay outputs per processor
  • - Multiple detection zones can be assigned to an output
• Processor
  • - Installed in the traffic controller cabinet or integrated into the camera housing
• Communications
  • - Wired or wireless transmission of video or detection signals over TCP/IP network
